[2] For purposes of TSS reduction calculations, Table 2 below presents the presumed removal rates for certain BMPs designed in accordance with the New Jersey Stormwater Best Management Practices Manual. The BMP Manual may be obtained from the address identified in Subsection G below, or found on the Department's website at www.njstormwater.org. The BMP Manual and other sources of technical guidance are listed in | |||||||
[3] If more than one BMP in series is necessary to achieve the required 80 percent TSS reduction for a site, the applicant shall utilize the following formula to calculate TSS reduction: | |||||||
R.= A + B - (AXB)/100 Where
| |||||||
R.= total TSS percent load removal from application of both BMPs; and
| |||||||
A.= the TSS percent removal rate applicable to the first BMP
| |||||||
B.= the TSS percent removal rate applicable to the second BMP
| |||||||
| |||||||
![]() | |||||||
[4] If there is more than one onsite drainage area, the 80 percent TSS removal rate shall apply to each drainage area, unless the runoff from the sub-areas converge on site in which case the removal rate can be demonstrated through a calculation using a weighted average. | |||||||
(b) Nutrients. Stormwater management measures shall also be designed to reduce, to the maximum extent feasible, the post-construction nutrient load of the anticipated load from the developed site in stormwater runoff generated from the water quality design storm. In achieving reduction of nutrients to the maximum extent feasible, the design of the site shall include nonstructural strategies and structural measures that optimize nutrient removal while still achieving the performance standards in | |||||||
(c) Additional information. Additional information and examples are contained in the New Jersey Stormwater Best Management Practices Manual, which may be obtained from the address identified in | |||||||
(d) FW 1 waters. In accordance with the definition of FW 1 at N.J.A.C. 7:9B-1.4, stormwater management measures shall be designed to prevent any increase in stormwater runoff to waters classified as FW 1 .
| |||||||
(e) Category 1 waters. Special water resource protection areas shall be established along all waters designated Category One at N.J.A.C. 7:913, and perennial or intermittent streams that drain into or upstream of the Category One waters as shown on the USGS Quadrangle Maps or in the County Soil Surveys, within the associated HUC14 drainage area. These areas shall be established for the protection of water quality, aesthetic value, exceptional ecological significance, exceptional recreational significance, exceptional water supply significance, and exceptional fisheries significance of those established Category One waters. These areas shall be designated and protected as follows:
| |||||||
[1] The applicant shall preserve and maintain a special water resource protection area in accordance with one of the following: | |||||||
[a] A 300-foot special water resource protection area shall be provided on each side of the waterway, measured perpendicular to the waterway from the top of the bank outwards or from the centerline of the waterway where the bank is not defined, consisting of existing vegetation or vegetation allowed to follow natural succession is provided. | |||||||
[b] Encroachment within the designated special water resource protection area under Paragraph [1 ][a] above shall only be allowed where previous development or disturbance has occurred (for example, active agricultural use, parking area or maintained lawn area). The encroachment shall only be allowed where applicant demonstrates that the functional value and overall condition of the special water resource protection area will be maintained to the maximum extent practicable. In no case shall the remaining special water resource protection area be reduced to less than 150 feet as measured perpendicular to the top of bank of the waterway or centerline of the waterway where the bank is undefined. All encroachments proposed under this subparagraph shall be subject to review and approval by the Department. | |||||||
[2] All stormwater shall be discharged outside of and flow through the special water resource protection area and shall comply with the Standard for Off-Site Stability in the "Standards For Soil Erosion and Sediment Control in New Jersey," established under the Soil Erosion and Sediment Control Act, N.J.S.A. 4:24-39 et seq. | |||||||
[3] If stormwater discharged outside of and flowing through the special water resource protection area cannot comply with the Standard For Off-Site Stability in the "Standards for Soil Erosion and Sediment Control in New Jersey," established under the Soil Erosion and Sediment Control Act, N.J.S.A. 4:24-39 et seq., then the stabilization measures in accordance with the requirements of the above standards may be placed within the special water resource protection area, provided that: | |||||||
[a] Stabilization measures shall not be placed within 150 feet of the Category One waterway; | |||||||
[b] Stormwater associated with discharges allowed by this section shall achieve a 95 percent TSS post-construction removal rate; | |||||||
[c] Temperature shall be addressed to ensure that there is no detrimental impact on the receiving waterway; | |||||||
[d] The encroachment shall only be allowed where the applicant demonstrates that the functional value and overall condition of the special water resource protection area will be maintained to the maximum extent practicable; | |||||||
[e] A conceptual project design meeting shall be held with the appropriate Department staff and Soil Conservation District staff to identify necessary stabilization measures; and | |||||||
[f] All encroachments proposed under this section shall be subject to review and approval by the Department. | |||||||
[4] A stream corridor protection plan may be developed by a regional stormwater management planning committee as an element of a regional stormwater management plan, or by the Village through an adopted municipal stormwater management plan. If such a stream corridor protection plan for a waterway subject to | |||||||
[5] | |||||||
(7) Standards for structural stormwater management measures.
| |||||||
Standards for structural stormwater management measures are as follows: | |||||||
(a) General.
| |||||||
[1] Structural stormwater management measures shall be designed to take into account the existing site conditions, including, for example, environmentally critical areas, wetlands; flood-prone areas; slopes; depth to seasonal high water table; soil type, permeability and texture; drainage area and drainage patterns; and the presence of solution-prone carbonate rocks (limestone). | |||||||
[2] Structural stormwater management measures shall . be designed to minimize maintenance, facilitate maintenance and repairs, and ensure proper functioning. | |||||||
[3] Structural stormwater management measures shall be designed, constructed, and installed to be strong, durable, and corrosion resistant. Measures that are consistent with the relevant portions of the Residential Site Improvement Standards at N.J.A.C. 5:21-7.3, 7.4, and 7.5 shall be deemed to meet this requirement. | |||||||
[4] Stormwater management basins shall be designed to meet the minimum safety standards for stormwater management basins at | |||||||
[5] Manufactured treatment devices may be used to meet the requirements of | |||||||
[6] Stormwater management measure guidelines are available in the New Jersey Stormwater Best Management Practices Manual. Other stormwater management measures may be utilized provided the design engineer demonstrates that the proposed measure and its design will accomplish the required water quantity, groundwater recharge and water quality design and performance standards established by | |||||||
(b) Trash racks. A trash rack is a device designed to catch trash and debris and prevent clogging of outlet structures. Trash racks shall be installed at the intake to the outlet from the stormwater management basin to ensure proper functioning of the basin outlets in accordance with the following:
| |||||||
[1] Trash racks shall have parallel bars with one-inch (1 ") spacing between the bars to the elevation of the water quality design storm. | |||||||
[2] For elevations higher than the water quality design storm, the parallel bars at the outlet structure shall be spaced no greater than one-third () the width of the diameter of the orifice or one-third () the width of the weir, with a minimum spacing between bars of one-inch and a maximum spacing between bars of six inches. | |||||||
[3] At the intake to the outlet from the stormwater management basin, the orifice size shall be a minimum of two and one-half (2.5) inches in diameter. | |||||||
[4] The design of trash racks must also comply with the requirements of | |||||||
(c) Grates and inlets to prevent discharge of trash and debris from drainage systems. Site design features identified ,under | |||||||
[1] Design engineers shall use either of the following grates whenever they use a grate in pavement or another ground surface to collect stormwater from that surface into a storm drain or surface water body under that grate: | |||||||
[a] The New Jersey Department of Transportation (NJDOT) bicycle safe grate, which is described in Chapter 2.4 of the NJDOT Bicycle Compatible Roadways and Bikeways Planning and Design Guidelines (April 1996); or | |||||||
[b] A different grate, if each individual clear space in that grate has an area of no more than seven (7) square inches, or is no greater than one-half (0.5) inch across the smallest dimension. | |||||||
Examples of grates subject to this standard include grates in grate inlets, the grate portion (non-curb-opening portion) of combination inlets, grates on storm sewer manholes, ditch grates, trench grates, and grates of spacer bars in slotted drains. Examples of ground surfaces include surfaces of roads (including bridges), driveways, parking areas, bikeways, plazas, sidewalks, lawns, fields, open channels, and stormwater basin floors. | |||||||
[2] Whenever design engineers use a curb70pening inlet, the clear space in that curb opening (or each individual clear space, if the curb opening has two or more clear spaces) shall have an area of no more than seven (7) square inches, or be no greater than two (2) inches across the smallest dimension. | |||||||
[3] This standard does not apply: | |||||||
[a] Where the review agency determines that this standard would cause inadequate hydraulic performance that could not practicably be overcome by using additional or larger storm drain inlets that meet these standards; | |||||||
[b] Where flows from the water quality design storm as specified in | |||||||
[i] A rectangular space four and five-eighths inches long and one and one-half (1 .5) inches wide (this option does not apply for outfall netting facilities); or | |||||||
[ii] A bar screen having a bar spacing of one-half (0.5) inch. | |||||||
